Screw Press Dewatering System

High-Efficiency Solid-Liquid Separation Technology

Jiahe Conveying's Screw Press Dewatering System delivers exceptional performance in sludge and material dewatering applications. Our advanced screw press technology achieves 18-40% dry solids content with 30% lower energy consumption compared to conventional dewatering equipment.

Key Advantages

• Continuous operation with automatic adjustment

• Low polymer consumption (30-50% reduction)

• Self-cleaning design minimizes maintenance

• Compact footprint saves installation space

• Proven in 500+ installations worldwide

Technical Specifications

Innovative Design Features

1. Advanced Dewatering Mechanism

• Gradual pitch reduction (3:1 compression ratio)

• Counter-pressure cone adjustment

• Multi-stage dewatering zones

2. Robust Construction

• Hard-faced screw flights (HRC 58+)

• Wear-resistant screen (50,000h lifespan)

• Heavy-duty bearings (L10 60,000h)

3. Smart Control System

• Automatic torque adjustment

• Polymer optimization control

• Remote monitoring interface

• Predictive maintenance alerts

Performance Data

Municipal Sludge Dewatering Results:

• Feed solids: 2-5%

• Cake solids: 22-28%

• Capture rate: >95%

• Power consumption: 0.8-1.2 kWh/m³

Industry Applications

Wastewater Treatment

• Municipal sludge dewatering

• Industrial wastewater solids

• Digestate processing

Food Processing

• Fruit/vegetable waste

• Brewery/dairy byproducts

• Starch processing

Industrial

• Paper mill sludge

• Chemical precipitates

• Mining tailings

Why Choose Our Screw Press?

✔ Higher dryness than competitive models
✔ Lower operating costs with energy savings
✔ Simpler maintenance with quick-release parts
✔ Smart controls for optimal performance

Request a performance comparison for your application!
