Tapered Inner Screw Flight (Internal Conical Spiral Blade)

Product Overview

Tapered Inner Screw Flights feature a conical inner bore design that progressively changes diameter along the shaft axis. These specialized spiral blades are engineered for applications requiring controlled material compression, precise feeding, or variable flow rates in constrained spaces. The unique internal taper geometry enables optimized material handling in compact equipment configurations.

Key Features

1. Precision Tapered Bore - Gradually decreasing/increasing inner diameter

2. Space-Saving Design - Compact profile for equipment with limited installation space

3. Material Flow Control - Regulates feed rate and material compression

4. Heavy-Duty Construction - Available in carbon steel, stainless steel, or wear-resistant alloys

5. Balanced Configuration - Computer-optimized design for vibration-free operation

6. Customizable Geometry - Adjustable taper angles and pitch configurations

Technical Specifications

Performance Advantages

✔ Controlled Material Compression - Progressive diameter change regulates density ✔ Space Optimization - Ideal for compact equipment designs ✔ Reduced Wear - Reinforced inner edges for extended service life ✔ Energy Efficiency - Optimized flow reduces power requirements ✔ Process Flexibility - Adjustable compression ratios

Primary Applications

Material Processing

• Feed systems for extruders and compounders

• Biomass densification equipment

• Powder compression systems

Industrial Manufacturing

• Plastic pellet conveying

• Food product forming

• Chemical processing

Specialty Applications

• Waste compaction systems

• Agricultural feed processing

• Mineral concentrate handling

Custom Engineering Services

• 3D Flow Simulation - Material movement analysis

• Taper Optimization - For specific compression requirements

• Prototype Development - Functional testing units

• Complete System Integration - Including shaft adapters

Quality Assurance

• ISO 9001:2015 certified production

• Dimensional accuracy within ±0.2mm/m

• Material certification available

• Non-destructive testing options

• Full quality documentation
